FDB CL4023 kültéri oszlop sugárzó

Black or white
The CL4023 series is a 4”, two-way,all-weather column speaker with different colours or functions, with waterproof, dustproof, windproof, anti-uv aging, dustproof and waterproof covers specially designed for input and output, and multi-layer different functional grille. The product meets the IP56 standard. The exposed metal parts are sprayed with stainless steel or aluminum, and the mounting bracket is sprayed with low-carbon steel to meet all-weather use. The sound is soft and balanced. Unit configuration: 2x4" 25mm voice coil ferrite mid-bass units, 1x1" exit throat 34mm HF driver with horn, the cabinet is made of  aluminum alloy, and the upper and lower panels of the cabinet are die-cast. The B and W after the model represent black, T represents the configuration of transformer and band switch to achieve a variety of different output powers including constant resistance.



MODEL
CL4023B/CL4023W
CL4023BT/CL4023WT


FREQUENCY RESPONSE(-10dB)
120Hz-18kHz
120Hz-18kHz


DRIVERS
2×4"(100mm)/1"voice coil LF
2×4"(100mm)/1"voice coil LF



1×1"(25mm)/1.4"voice coil HF
1×1"(25mm)/1.4"voice coil HF


INPUT VOLTAGE

100V


RATED POWER
65W RMS,260W peak
15W/30W/60W/OFF/8Ω65W


SENSITIVITY
91dB 1watt/1 metre
91dB 1watt/1 metre


MAXIMUM SPL
109dB continuous,115dB peak
109dB continuous,115dB peak


IMPEDANCE
8 ohms nominal
8 ohms nominal


DISPERSION(-6dB)
100°×60°
100°×60°


CROSSOVER FREQUENCIES
1.8kHz passive
1.8kHz passive


INPUT CONNECTORS
M22-2P
M22-2P


PACKAGE SIZE
517mm×380mm×193mm(1Pair)
517mm×380mm×193mm(1Pair)


NET WEIGHT
5.5 kg/pc
6 kg/pc


GROSS WEIGHT
13 kg/pair
14 kg/pair
