ODIN T-8A aktív line array modul

 • CELESTION components inside
• Waveguide for optimized low-mid frequency directivity
• Single user 3-point suspension system
• DSP optimized Amplification ensures highest reliability
• Multivoltage Power supply with active PFC
System: 2-way full range, Active Array Element
AMP Power: 800 W Continuous, Bi-AMP(Class D-650 W LF, Class AB-150 W HF), 3200W Peak
Speaker: 2x 1" Celestion Neodymium Compression Driver,1.75" Voice Coil, 80W RMS, 320W Peak
2x 8" Celestion Neodymium MID Woofer, Water Resistant Coating, 2– Voice Coil, 400W-RMS/1600W-Peak
Frequency Response (+/-3dB): 80 Hz - 19 kHz
MAX SPL @ 1m: 129dB
Crossover frequency: 1,6 KHz
Dispersion(-6dB): 100° Horizontal / 10° Vertical
Cooling: Passive Cooling + forced cooling inside
Audio Connector: XLR In- and output
Data Connector: RJ45 Date In & Link Cascading Connector
External Controls: 9 Fixed Preset + 1 Editable preset, Power Switch with LED indicators for Clip / SIG / PROT
DSP Processor: 32 bit , 24bit/48kHz Audio conversion AD/DA
Electronic Protections: Thermal / Convection-Fan / Overload / Digital Limiter / Compressor
Mains Connector: Neutrik PowerCON Connector In & Out
Power Supply: 100 ~ 240VAC, 50Hz/60Hz
Power Consumption: 1100W
Enclosure Construction: 18mm Birch Plywood, Resistant Black Paint, 1.5T Metal Grill with Foam, Two Handles on Each Side, Water Resistant Coating
Mounting: 3-point Suspension, Horizontal Trapezoid 2 x 6.5°
Dimensions (LxWxH): 635 x 468 x 300 mm
Net Weight: 22.5 Kg / 49.5 Ibs
Optional Accessories: Flybar
Polemount Adaptor
Ground stacking feet
Flying Pin
DSP Network Interface
